FEATURES
- IGBT inverter and output isolation transformer
- 3 phases UPS allow 100% unbalanced load
- Fully DSP control, high reliability and performance
- HMI-touch screen display
- DC cold start function
- Advanced battery charging management
- Battery self-test function
- Intelligent fan speed control
- ECO mode and EPO function
- Optional no-master-slave parallel technology
- The output isolation transformer provides high reliability to adapt to different harsh industrial environments and the protects the critical loads
SPECIFICATION
| SPECIFICATION | VALUE |
| CAPACITY | 100KVA |
| PHASE | THREE PHASE (3 PHASE + N + PE) |
| INPUT VOLTAGE | 208/220 + 25% |
| FREQUENCY | 40 ~ 70Hz |
| POWER FACTOR | 0.8 |
| OUTPUT VOLTAGE | L-N: 120/127 ± 1%; L-L 208/220 ± 1% |
| OUTPUT VOLTAGE REGULATION | +/- 1% |
