Features
- 30 KVA power module in 3U height and less than 34kg
- Indpendent LCD for power module
- 10.4” touch color LCD with graphic display
- High efficiency up to 95%
- Smart sleep function that intelligently shutdown some power modules to increase total load rate, achieving higher efficiency
Specification
| Specification | Value |
| CAPACITY | 180KVA 300KVA 600KVA |
| POWER MODULE | 30KVA |
| PHASE | THREE PHASE IN; THREE PHASE OUT 3 PHASES + NEUTRAL + GROUND |
| INPUT VOLTAGE | 304 ~ 478VAC (LINE – LINE), FULL LOAD |
| FREQUENCY | 40 ~ 70Hz |
| INPUT POWER FACTOR | >0.99 |
| RATED VOLTAGE | 380/400/415VAC (LINE-LINE) |
| RATED FREQUENCY | 50/60 Hz |
| OUTPUT POWER FACTOR | 0.9 |
