FEATURES
- IGBT inverter and output isolation transformer
- 3 phases UPS allow 100% unbalanced load
- Fully DSP control, high reliability and performance
- HMI-touch screen display
- DC cold start function
- Advanced battery charging management
- Battery self-test function
- Intelligent fan speed control
- ECO mode and EPO function
- Optional no-master-slave parallel technolog
- The output isolation transformer provides high reliability to adapt to different harsh industrial environments and the protects the critical loads
SPECIFICATION
| SPECIFICATION | VALUE |
| CAPACITY | 10KVA, 20KVA, 30KVA, 40KVA, 60KVA, 80KVA, 100KVA, 120KVA, 160KVA, 200KVA, 250KVA, 300KVA, 400KVA, 500KVA, 600KVA |
| PHASE | THREE PHASE (3 PHASE + N + PE) |
| INPUT VOLTAGE | 380VAC/400VAC/415VAC ± 25% |
| FREQUENCY | 40 ~ 70Hz |
| POWER FACTOR | 0.9 (0.8/1.0 OPTIONAL) |
| OUTPUT VOLTAGE | L-N: 220/230/240 ± 1%; L-L 380/400/415 ± 1% |
| OUTPUT VOLTAGE REGULATION | +/- 1% |
